2.47 Inch Circular LCD Panel/Screen/Display 480x480 Round 35PIN MIPI 400nits TFT LCD Display

2.47 Inch Circular LCD Panel/Screen/Display 480x480 Round 35PIN MIPI 400nits TFT LCD Display

EXSON

EX02403-A01 2.47 Inch Circular LCD Panel/Screen/Display is a color active matrix TFT-LCD Panel using amorphous silicon TFT's (Thin Film Transistors) as an active switching devices. This model is composed of a TFT-LCD Panel, a driving circuit and a back light system. It is a transmissive type display operating in the normal black. This TFT-LCD has a 2.47 inch diagonally measured active area with resolutions 480 horizontal by 480 vertical pixel array. Each pixel is divided into Red, Green, Blue dots which are arranged in 2 domain stripe and this panel can display 16.7M colors.It is Suitable for vehicle mounted, handheld terminal, industrial LCD, etc.

General Specifications of 2.47 Inch 480x480 Round 35PIN MIPI 400nits-1
No. Item Specification
1 LCD size 2.47 inch
2 Resolution 480x480
3 Active area 62.64×62.64(circle)mm
4 Module size 69.19(H)×71.74(V)×2.45(D) mm
5 Interface MIPI
6 Brightness 400cd/m2
7 Contrast Ratio 1000:1
8 Driver IC HX8379-C
9 Polarizer Transmissive
10 Display Colors 16.7M
11 Viewing Direction All
12 Weight 25g (Max)

Outline Dimension of 2.47 Inch 480x480 Round 35PIN MIPI 400nits-1

As a professional tft lcd screen factory, we provide china custom lcd display, circular lcd display module, circular tft, circular lcd panel, circular display screen, circular tft display, circle lcd display, circular lcd screen, circular lcd, china lcd display tft, etc. For more information, please feel free to contact us!
